Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: MOLLELEC
  • Model Number: F360 RCCB
  • Type: Residual Current
  • Poles Number: 1 2 3 4
  • color: white RCCB
  • body material: PA66
  • the inside parts: IEC standard accessaries
  • key word: ID Residual Current Circuit Breaker

Packaging & Delivery

Packaging Details: Sandard Export Packing,Carton RCCB
Delivery Detail: 3-7DAYS

Specifications

1.Rated voltage:240V RCCB
2.Rated current:6~63A
3.Leakage current:30/100MA
4.Poles:2P
5.Standard:IEC61008

Current Circuit Breaker/RCCB



1.CB/CE/SEMKO certificates
2.abundant OEM experiences
3.high stability and safe characteristics
4.two poles and 10KA breaking

residual current circuit breaker Technical data

·Rated Current(In)             16,25,32,40,63,80A
·Rated Voltage(Un)            230V,400V
·Breaking capacity              6kA
·Rated Tripping Current     10mA,30mA,100mA,300mA
·Type                                      AC
·Number of Poles                1P+N,3P+N
·Type of Terminal                Lug type
·Termianl Capacity               cable up to 35mm2
·Standards                          IEC61008,EN 61008

APPLICATIONS:





F360 F362 F364 Residual Current Circuit Breaker RCD

F360(F362,F364) series Residual Current Circuit Breaker without over current protection conforms to the standards of GB16916.1, IEC1008, BS4293 etc. It is used in the circuits of AC 50~60Hz, single phase 230V(220V), three phases 400V (380V) in industrial & mining enterprises, commercial buildings and housing for protection of personal electric shock hazard and electric equipment and for unfrequent switchover of
circuits under normal conditions.

Features:
Number of Poles: 4P
Rated Current (A): 16, 20, 25, 32, 40, 50, 63, 80, 100
Rated Residual Operating Current (mA): 10, 30, 100, 300, 500
Rated Residual Non-operation Current (mA): ≤0.5
Rated Voltage (V): AC 230/240


The CC60NL RCCB incorporates a residual current operated eletromagnetic release which operates without any auxiliary source of supply to open a circuit automatically in the case of an earth leakage fault between phase earth greater than or equal to IΔn.
The CC60NL combined MCB&RCCB provides:

1.       protection against indirect contact
2.       complementary protection against direct contact
3.       protection for the installation against insulation faults
